PN2 CxE CLEAR PVC SUCTION HOSE

Hose By Material

Hose By Application

Select a Hose

Accessories

OverviewThe Model PN2 is lightweight, high quality PVC hose designed for a wide variety of suction or transfer applications. It is constructed from a flexible corrugated, clear PVC with a smooth bore, and an external rigid PVC helix that allows for easy dragging.

Here it is made available for quick purchase with popular aluminum CxE (male x female) cam & groove fittings for 1" to 12" diameters in 50ft lengths. Also avaialble here with NPSH MxF Swivel fittings.

  • Suction Ready
  • Bends Better than Other PVC Suction Hoses
  • Lightweight and Easily Dragged
  • Transulcent for Flow Check
  • Smooth Bore

 Applications:

  • Industrial and Construction Liquid and Material Service where Mild Chemical Resistance is Required
  • Pump Suction Sevice

Temperature:  5F to 150F

scroll to see more products
Dia
(in)
Outer Dia
(in)
Lngth-ft
(ft)
FittingsPres
(psi)
Vac
(in Hg)
Bend R
(in)
Wt
(lbs)
NoteProduct NoWt/Ft
(lbs)
Price
($)

1 1/2 2.03 20 CAM & GRV M X F AL 100 28 3 15   HOSE-PN2AS20CE0150 .47 $165.30 Add to Cart
2 2.62 20 CAM & GRV M X F AL 100 28 4 19   HOSE-PN2AS20CE0200 .71 $185.50 Add to Cart
3 3.71 20 CAM & GRV M X F AL 100 28 6 27   HOSE-PN2AS20CE0300 1.14 $237.90 Add to Cart
4 4.80 20 CAM & GRV M X F AL 75 28 7 42   HOSE-PN2AS20CE0400 1.75 $351.50 Add to Cart
6 7.17 20 CAM & GRV M X F AL 70 28 10 86   HOSE-PN2AS20CE0600 3.90 $766.00 Add to Cart
