PD1 MxF NPSH PVC LAYFLAT DISCHARGE HOSE

Hose By Material

Hose By Application

Select a Hose

Accessories

OverviewThe Model PD1 is a PVC standard duty  lay-flat hose for water discharge. Reinforcement includes spiral plies and longitudinal synthetic cords for burst resistance. Other varieties for higher pressures alternate materials are also available.

Here it is made available for quick purchase with popular NPSH MxF (male x female swivel) thread fittings for 1-1/2" to 6" diameters in 50ft lengths. Also avaialble here with aluminum CxE cam & groove fittings.

Features:

  • Rolls up Compactly for Storage
  • Economical
  • Resists Kinking and Twisting

Applications

  • Water Discharge for Industrial and Construction

Temperature:  5F to 130F

scroll to see more products
Dia
(in)
Lngth-ft
(ft)
Fittings Pres
(psi)
Wt
(lbs)
Product No Wt/Ft
(lbs)
Price
($)
Lead Time
(days)

1 1/250NPSH M X F SW8012HOSE-PD1AS50MF01500.19$71.863 Add to Cart
250NPSH M X F SW8015HOSE-PD1AS50MF02000.24$83.203 Add to Cart
2 1/250NPSH M X F SW6519HOSE-PD1AS50MF02500.30$200.723 Add to Cart
350NPSH M X F SW8022HOSE-PD1AS50MF03000.36$166.203 Add to Cart
450NPSH M X F SW7031HOSE-PD1AS50MF04000.53$235.883 Add to Cart
650NPSH M X F SW3549HOSE-PD1AS50MF06000.87$486.203 Add to Cart
